High Pressure One-Key Query Function Pressure Performance Automatic
Autoclave Sterilizer
Automatic Autoclave Sterilizer Instrument introduction :
Instrument introduction: CT115C is aimed at the needs of
enterprises for large-capacity sterilization, and launched a
cabinet-type and top-opening-door autoclave (CT-series) with an
independent steam generator; and the original product line: desktop
autoclave (D-series) , Vertical autoclave (V-series), forming a
more complete series of high temperature and high pressure
sterilization products, providing continuous innovation and
high-quality services for laboratory, industrial and medical
customers.
Automatic Autoclave Sterilizer Main features and functions :
◆ Sterilization temperature: 105-138℃
◆ Six preset programs: preset six fixed programs for liquid
sterilization and heat preservation, solid sterilization and
drying, agar melting heat preservation and waste sterilization,
etc.
◆ Timed start function: The start time can be reserved, so that the
sterilizer will automatically start at the scheduled time.
◆ Memory storage system: Users can set their own parameters, create
multiple programs and call them at any time, and set the authority
to use the instrument to three levels: user, administrator, and
engineer, which is convenient for the good use and management of
the sterilizer
◆ Drying function: dry completely, in line with CE standard cooling
lock.
◆ Exhaust steam control: After the sterilization is completed, the
exhaust valve can automatically open the exhaust steam according to
the preset temperature.
◆ With memory function, the working program of the autoclave will
not be lost even after the power is cut off, and the autoclave
program can be restored by reconnecting the power supply.
◆ The CT-series autoclave combines heating, sterilization, exhaust,
heat preservation, fusion and other steps to meet the processing
needs of different samples such as liquids, solids, waste, and
culture media. The autoclave is equipped with a drying setting to
provide an operation mode with drying
◆ Zero steam emission: from the start to the end, no steam is
discharged, effectively preventing the spread of the virus
◆ Automatic water intake: no need to add water manually, which
greatly improves work efficiency
| model | CT115 Dry sterilizer |
| Timer preset range | Query current time (year,Month,Day,Time,Minute) |
| Total number of sterilization and failure time and code |
| Pressure gauge display range | 0～0.6Mpa |
| pressure | The cavity design pressure is 0.4MPa. |
| The corresponding number of each product has the original product
quality certificate of the manufacturer and the original
certificate issued by the special equipment manufacturing
supervision and inspection department |
| Pressure safety protection | Two independent pipeline measurement control,Mechanical and
electronic dual pressure protection |
| Sterilization mode | Solid mode: heating → sterilization → exhaust, air cooling |
| Solid belt drying mode: heating → sterilization → drainage, exhaust
→ drying |
| Liquid mode: heating → sterilization → pre-cooling → exhaust |
| Liquid belt insulation mode: heating → sterilization → pre-cooling
→ exhaust → heat preservation |
| Waste mode: heating → sterilization → exhaust, air cooling |
| Agar mode: heating → melting → heat preservation |
| Exhaust steam control and water tank | Fully automatic internal discharge (see instructions for exhaust
temperature setting), built-in large-capacity steam condensate
collection bottle and water storage tank |
Shandong Haiying Wuzhou Instrument Co., Ltd.
Strong qualifications, brand certification
◆ Professional power
Sets of medical equipment, pharmaceutical equipment of scientific
research, production and sales, medical service, trade logistics in
various fields of domestic leading health industry group.
◆ Professional power
The infection control equipment production of varieties and ranked
among the top of the world; Radiation therapy equipment r &d
and production in domestic large scale, complete varieties,
domestic market share is high, the technical level of lead.
◆ Quality management
With medical devices and equipment, pharmaceutical equipment,
medical services,- medical commerce four business sectors.Advanced
technology, strong innovation ability, selections of the management
system, and perfect service.
